GENERAL INFORMATION
90″, 55 kWh90″, 75 kWh110″, 90 kWh
Maximum speed, km/h
130 (limited by software)
Acceleration till 100 km/h, s
111011
Operating conditions
-20˚C to +45˚C
Vehicle range (mixed cycle), km
185250300
HV BATTERY PACK AND CHARGING
Basic capacity, kWh, brutto
557590
Battery technology
NCM 712
Basic capacity, kWh, brutto
350 (317…403)500 (436…554)575 (515…655)
Battery cell protection
Balancing by BMS on all cells
Battery pack protection
Fully protected against overcurrent, over-and under-voltage, excessive temperature, and overcharging
Battery AC charger
22 kW
Charging time AC (to basic capacity at 22 kW AC charging), hours
3,244,7
Combined charging system (CCS)
optional
Battery DC fast charging
up to 70 kWup to 100 kWup to 115 kW
Charging time DC
(20 to 80% SOC), min
303030
Battery cooling/heating
Liquid cooling and heating system of battery modules
DRIVE SYSTEM
Propulsion motor power, peak/continuous, kW
190/115180/110215/125
Propulsion motor torque, peak/continuous, Nm
775/430950/420950/420
Power electronics for drive
Permanent magnet propulsion motor, Inverter on IGBT transistors
Transmission scheme
Propulsion electric motor – Transverse case
(low- and high-speed) – Drive axles
Cooling system
Liquid cooling system of electric drive motor and power electronics
DISPLAY OPTIONS
Original (series and Defender), Puma, LCD 12”
